Description
Designed from the ground up for gravel, Terra isn’t a repurposed road bike or a slimmed down mountain bike. Add comfort to your road adventures, finally discover where that dirt trail leads or let your trips spread overnight. There is a wide world out there and Terra is ready to explore it with you.
A MORE CAPABLE BIKE
Gravel is a universe of different users and terrains. For that reason Terra is a complete platform with different models in aluminium and carbon, offering the most inclusive solutions that won’t leave anyone indifferent.
FAST AND LIGHT ADVENTURES
Our Terra M is the sportiest option within the family, fast and light for those back roads or gravel path adventures.
The carbon frame offers the perfect blend of weight, comfort and strength while our LOCKR system takes care of storing those essentials. With our MyO program your Terra can be as unique as your adventures.
TIRE CLEARANCE
Terra can be mounted with 700c x 45 tires for speed and efficiency on dirt roads, or with 650b x 50 treads for extreme durability and high-volume comfort if you need a bit more traction.
DRIVETRAIN COMPATIBILITY
Designing our frame from the ground up gave us the opportunity to tackle a problem which exist in many gravel frames. Namely giving a range of drivetrain options without compromising tyre clearance.
LOCKR
Our Carbon frame offers a storage area inside the downtube, hidden behind the water bottle cage, where there is space for the tube, pump or CO2 cartridge, as well as a selection of tools.
GRAVEL GEOMETRY
Terra offers a completely new gravel design with gravel specific geometry. We have worked hard, using all our experience from both Road and MTB, to deliver a balanced ride, with precise handling and maximum control.
Outfitted with OQUO
The Oquo Road Control range lets you keep on riding long after the road ends. With a focus on robustness and comfort, these are the perfect addition to amp up your adventures.
Vibrant new patterns and graphics
Exciting new graphics and colors in both range and MyO let you pick your perfect gravel companion: dark and discreet or funky and flashy.
Specs
Frameset
Frame
Orbea Terra Hydro disc, hydroformed triple butted aluminium, HS 1,5″, PF, Thru Axle 12mm x 142mm rear, thread M12x2 P1, DT internal cable routing, 27,2mm seat tube, MMS system
Fork
Orbea Terra ICR, full carbon, 1-1/8″ – 1,5″ tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1
Steerer tube
FSA 1-1/2″ Integrated Aluminium Cup
Drivetrain
Crankset
Shimano GRX RX610 30x46t
Shifters
Shimano GRX RX610
Cassette
Shimano HG710 11-36t 12-Speed
Rear derailleur
Shimano GRX RX820
Front derailleur
Shimano GRX RX820
Chain
Shimano M6100
Cockpit
Handlebar
OC Gravel GR31-R, Rise 15, Reach 70, Drop 110
Stem
OC Road Performance RP22, -5º
Brakes
Brakes
Shimano RX400 Hydraulic disc
Brakes Configuration
N/A
Wheels
Wheels
Alloy, Tubeless, 700c, 21c
Tyres
Vittoria Terreno Dry Gravel 700x38c
Front Wheel Axle
Orbea Thru Axle 12x100mm M12x2 P1 Solid
Rear Wheel Axle
Orbea Thru Axle 12x142mm M12x2 P1 Solid inner threaded
Components
Seatpost
SP 0.2 Carbon, 27.2mm, Setback 20
Saddle
Prologo Akero AGX black rails size 155mm
Accessories
Mudguard Handlebar Tape
Orbea Eva
